TS AUTOMATIC FOLDER GLUER STITCHING MACHINE

Nail box technical parameters:

Count parameters of the sticky box part:

Machine function:

The automatic nailing machine is composed of paper supply, folding and stitching department, alignment and correction department. Frequency control, simple and reliable operation. Automatic folding, automatic counting, automatic stacking output. Average nail speed 80 m/min, 40-110 pieces. The adhesive speed is 170m/min, 100-300 pieces.

Paper supply department:

Adopt the belt leading edge suction paper, accurate and reliable.

Use high-grade electromagnetic clutch and electromagnetic brake system, so that the paper supply part can be controlled independently, simple and reliable operation.

Adjustable paper wheel, suitable for cardboard thickness of 2-12mm.

Linkage with the folding part, frequency control.

The front baffle of the paper supply section and the paper belt can be adjusted from left to right.

The main motor adopts frequency conversion speed regulation, the system has no noise, the speed regulation is flexible and stable.

Imported high friction belt conveyor cardboard, automatic folding.

The cardboard height adjustment structure made of high quality steel, quickly adjust the height of various sizes of the box and the length of the cardboard.

The suction belt of the paper part is made of high-tech materials, and the tension layer is seamlessly connected with the ring belt to ensure that the machine has no worries in use.

The paper suction motor and the main rotating motor are of high quality from Taiwan. High stability motor. * The selection of high-grade electromagnetic clutch and electromagnetic brake system, so that the paper supply part can be single or continuous operation, effectively control the waste of cardboard in the specification adjustment of the output of cardboard precision.

The main drive shaft (six square steel) is made of Shackming alloy by special process.

1. The fastest pasting speed is 110m/min, which can greatly improve the production efficiency.

2. The whole machine is controlled by PLC and touch screen, and can be operated by button.

3. Automatic paper feeding, automatic gluing, automatic folding, automatic correction, automatic counting, automatic stacking.

4. Adopt suction belt paper feeding mode, simple structure, fast speed, accurate paper feeding.

5. It has the function of pressing line and secondary pressing line to ensure the folding is more accurate.

6. With secondary correction function, eliminate the size of the mouth, reduce the rejection rate. With differential correction adjustment function, completely eliminate scissors and forks, folding more accurate.

7. The receiving and shaping department automatically counts, shapes, accumulates into code and outputs the whole code, with fast speed and high precision.

8. Set up a temporary storage mechanism, depth layout space with wind control, prevent the paper messy, so that the adhesive carton fully arranged and shaped.

9. Manual adjustment parts are all installed dial indicator, easy to operate.

10. It can be randomly matched with automatic packing and strapping machine, which is fast and saves labor.

Glued folded part:

The main motor adopts frequency conversion speed regulation, the system has no noise, the speed regulation is flexible and stable.

With stainless steel wheel glue, glue evenly, no fault, and save glue.

Folding part uses imported friction, super wear-resistant special materials made of seamless butt ring conveyor belt, accurate to complete the automatic folding of cardboard.

The gluing part uses high quality stainless steel gluing wheel for uniform gluing, saving gluing and high efficiency.

The folding section is equipped with a double-channel indentation correction device to accurately and effectively correct the deviation of the cardboard pit line, so that the entire carton can complete the most accurate folding.

Nail box department:

The main motor adopts frequency conversion speed regulation, the system has no noise, the speed regulation is flexible and stable.

With stainless steel wheel glue, glue evenly, no fault, and save glue.

Folding part uses imported friction, super wear-resistant special materials made of seamless butt ring conveyor belt, accurate to complete the automatic folding of cardboard

The gluing part uses high quality stainless steel gluing wheel for uniform gluing, saving gluing and high efficiency.

The folding section is equipped with a double-channel indentation correction device to accurately and effectively correct the deviation of the cardboard pit line, so that the entire carton can complete the most accurate folding.

Sticker department:

Belt type leading edge suction paper feed, accurate and fast.

Automatic glue supply, circular glue, never break glue, no need to manually add glue, saving time and effort.

Stainless steel coated rubber wheel, corrosion resistance, wear resistance, uniform glue, save glue, the amount of glue is about one third of the amount of artificial glue.

The folding part is equipped with adjustable multi-channel press wheel group, which makes the carton folding more smooth and the adhesion more beautiful and accurate.

Counting department carton accumulation correction, the output is safe and stable, accurate and error-free, digital control, simple operation, can be input without stopping.

Counting and stacking output unit：

Use digital control, simple operation, reliable action, can not stop the input data, automatic counting, accurate output.

Use belt to transport cartons, stacking neatly, stacking speed 12 ornaments/min.

With the function of correcting deviation, deviation can be adjusted.

Counting and pushing out by pneumatic method, reliable, accurate and fast action.
